Available in Custom Single 1ohm or 2ohm voice coil
Single 1ohm model
Carbon Fiber Dustcap
Carbon Fiber Cone
Dual Coil Options for Competition Burp Only
High Density Pressed Foam Surround
Aluminum Housing
RE- 0.9574 ohms
FS- 37.0416 Hz
Zmax- 44.0249 ohms
Qes- 0.3263
Qms- 14.6773
Qts- 0.3192
EBP- 113.5201 (ported/6th BP)
Le- 1.5994 mH (1KHz)
Diam- 318 mm (12.5197")
Sd- 79422.6006 mm^2 (123.1053 in^2)
Vas- 35.9193 L (1.2685 ft^3)
BL- 17.7349 N/A
Mms- 460.5586 g
Cms- 40.0844 uM/N
Kms- 24947.3594 N/M
Rms- 7.3031 R mechanical
Efficiency- 0.5257%
Sensitivity- 89.2256 dB @1w/1m
Sensitivity- 98.4455 dB @2.83vrms/1m
Krm- 8.132E-03 ohms Freq Dependent Resistance
Erm- 729.131E-03
Kxm- 27.445E-03 Henries Freq Dependent Reactance
Exm- 660.029E-03
Xmax- 19mm
----------------------------------------------------------------------
Ftest- 29.471 Hz
Ftest/Fms- 0.7956
Test Mass Used- 267.0000 g (53.4 nickels)
Test Mass (Ft=Fms*0.90)- 108.032 g
Test Mass (Ft=Fms*0.75)- 358.212 g
Fully capable of both Music and Competition.
Competition rating- 30,000w 3 seconds.
